When you build things and work around machinery, not everything falls under what the rest of the world calls “standard”.  Some jobs call for custom/special tools like our Extra Deep Impact Sockets.  Threaded rods and bolts in deep spots are reached easily and readily with these extra-long sockets.

We offer extra deep impact sockets with 1/4, 3/8”, 1/2”, 3/4″ ,1”, 1-1/2”, and #5 spline drives.  Prices quoted below are for a 12” length socket or shorter.  There is an additional charge for sockets longer than 12”.  These sockets are custom built to your length requirements.  When specifying the length, allow for the depth of the drive end plus clearance needed for your application.  Call for pricing on any other special requirements.  Sockets are made to order and usually ship in 5 days.  We may be able to expedite your order if needed.  Socket orders are shipped F.O.B. Pender, NE.

The following sockets are carried in stock:

DS 15/16 x 12 x 1/2” drive socket

DS 1-1/16 x 12 x 1/2” drive socket

DS 1-1/8 x 12 x 1/2″ drive socket

DS 1-1/4 x 12 x 1/2” drive socket

DS 1-5/8 x 12 x 1/2” drive socket

Other Custom Sockets Available

Sockets longer than 12”

1/4, 1-1/2”, #5 Spline drives available

6-point impact socket is standard

8-point and 12-point impact sockets also available

Special OD and ID requirements

Slotted sockets for hydraulic or electrical fittings

Any other special requirements, Call for pricing.

HR Manufacturing Co.  402-385-2114

How to specify socket order information:

DS (nut size) x (total socket length) x (drive size)

How to order:

e-mail sales@hrmfg.net with questions or fill out and submit the form below.  Make sure you include your company information and shipping address.  We will get back to you with a price quote and a phone # to call with your credit card information.  When the socket order is shipped, we will e-mail you with a copy of the invoice and the package tracking information.

Prices current as of January 1, 2025.

Extra Deep Impact Sockets 3/8″ Drive – 6 point – Longer Sockets Available

Extra Deep Impact Sockets 1/2″ Drive – 6 point – Longer Sockets Available

PART #	NUT SIZE	LENGTH	DRIVE	PRICE ≤12″
Extra Deep Impact Socket	1/2	4″  to 12″	1/2″	$75.20
Extra Deep Impact Socket	9/16	4″  to 12″	1/2″	$75.20
Extra Deep Impact Socket	5/8	4″  to 12″	1/2″	$75.20
Extra Deep Impact Socket	11/16	4″  to 12″	1/2″	$77.35
Extra Deep Impact Socket	3/4	4″  to 12″	1/2″	$77.35
Extra Deep Impact Socket	13/16	4″  to 12″	1/2″	$79.50
Extra Deep Impact Socket	7/8	4″  to 12″	1/2″	$79.50
Extra Deep Impact Socket – Stock	15/16	4″  to 12″	1/2″	$81.65
Extra Deep Impact Socket	1″	4″  to 12″	1/2″	$81.65
Extra Deep Impact Socket – Stock	1-1/16	4″  to 12″	1/2″	$87.02
Extra Deep Impact Socket – Stock	1-1/8	4″  to 12″	1/2″	$87.02
Extra Deep Impact Socket	1-3/16	4″  to 12″	1/2″	$87.02
Extra Deep Impact Socket – Stock	1-1/4	4″  to 12″	1/2″	$90.25
Extra Deep Impact Socket	1-5/16	4″  to 12″	1/2″	$94.55
Extra Deep Impact Socket	1-3/8	4″  to 12″	1/2″	$99.92
Extra Deep Impact Socket	1-7/16	4″  to 12″	1/2″	$105.07
Extra Deep Impact Socket	1-1/2	4″  to 12″	1/2″	$114.45
Extra Deep Impact Socket	1-9/16	4″  to 12″	1/2″	$115.25
Extra Deep Impact Socket	1-5/8	4″  to 12″	1/2″	$117.45
Extra Deep Impact Socket	1-11/16	4″  to 12″	1/2″	$119.67
Extra Deep Impact Socket	1-3/4	4″  to 12″	1/2″	$120.36
Extra Deep Impact Socket	1-13/16	4″  to 12″	1/2″	$122.50
Extra Deep Impact Socket	1-7/8	4″  to 12″	1/2″	$127.87
Extra Deep Impact Socket	1-15/16	4″  to 12″	1/2″	$134.32
Extra Deep Impact Socket	2″	4″  to 12″	1/2″	$144.00
Extra Deep Impact Socket	2-1/4	4″  to 12″	1/2″	$159.05
Extra Deep Impact Socket	2-3/8	4″  to 12″	1/2″	$225.70
Extra Deep Impact Socket	2-1/2	4″  to 12″	1/2″	$236.45
Extra Deep Impact Socket	2-3/4	4″  to 12″	1/2″	$295.95
Extra Deep Impact Socket	13mm	4″  to 12″	1/2″	$70.90
Extra Deep Impact Socket	14mm	4″  to 12″	1/2″	$70.90
Extra Deep Impact Socket	15mm	4″  to 12″	1/2″	$70.90
Extra Deep Impact Socket	16mm	4″  to 12″	1/2″	$70.90
Extra Deep Impact Socket	17mm	4″  to 12″	1/2″	$70.90
Extra Deep Impact Socket	18mm	4″  to 12″	1/2″	$70.90
Extra Deep Impact Socket	19mm	4″  to 12″	1/2″	$71.97
Extra Deep Impact Socket	20mm	4″  to 12″	1/2″	$74.12
Extra Deep Impact Socket	21mm	4″  to 12″	1/2″	$77.35
Extra Deep Impact Socket	22mm	4″  to 12″	1/2″	$77.35
Extra Deep Impact Socket	23mm	4″  to 12″	1/2″	$79.50
Extra Deep Impact Socket	24mm	4″  to 12″	1/2″	$79.50
Extra Deep Impact Socket	25mm	4″  to 12″	1/2″	$87.02
Extra Deep Impact Socket	26mm	4″  to 12″	1/2″	$87.02
Extra Deep Impact Socket	27mm	4″  to 12″	1/2″	$87.02
Extra Deep Impact Socket	28mm	4″  to 12″	1/2″	$88.10
Extra Deep Impact Socket	29mm	4″  to 12″	1/2″	$88.10
Extra Deep Impact Socket	30mm	4″  to 12″	1/2″	$88.10
Extra Deep Impact Socket	31mm	4″  to 12″	1/2″	$92.40
Extra Deep Impact Socket	32mm	4″  to 12″	1/2″	$92.40
Extra Deep Impact Socket	33mm	4″  to 12″	1/2″	$94.55
Extra Deep Impact Socket	34mm	4″  to 12″	1/2″	$113.90
Extra Deep Impact Socket	36mm	4″  to 12″	1/2″	$117.12
Extra Deep Impact Socket	38mm	4″  to 12″	1/2″	$122.50
Extra Deep Impact Socket	41mm	4″  to 12″	1/2″	$125.72
Extra Deep Impact Socket	46mm	4″  to 12″	1/2″	$157.97
Extra Deep Impact Socket	50mm	4″  to 12″	1/2″	$199.90

Extra Deep Impact Sockets 3/4″ Drive – 6 point – Longer Sockets Available

Extra Deep Impact Sockets 1″ Drive – 6 point – Longer Sockets Available
